2020 new 4ch 6ch 8ch mdvr kit 4g mobile dvr truck bus dvr car video
-
$65.00 / 2 - 49 units
$55.00 / 50 - 99999 units
$35.00 / >=100000 units - 2 units
- Shenzhen Tianyou Security Technology Co., Ltd.
- Guangdong, China
- Mr Sancho Wang
Product Detail
| Video compression format: | H.265 | Storage: | 2*256GB SD card |
| Optional features: | RS485/RS232 | model: | LSZ-B5804DG-LF-D13 |
| place of origin; place of origin: | Guangdong, China | Video Compression: | H.265 Advanced |
| Alarm Output: | 4-way alarm output | port: | Shenzhen |
| Certificate: | CE FCC RoHS ISO9001 | Packaging Details: | Well packed in standard box |
| Supply capacity: | 1000 pieces per day | payment terms: | T/T, Western Union, MoneyGram |
| Recording mode: | Video and audio simultaneous recording | Alarm input: | 4CH alarm input |
| software platform: | CMSV6 | Package preview: | |
| Two-way dialogue: | Yes | power supply: | DC 8-36V |
| brand: | LSZ |
contact details | ||
e-mail | ||
Whatsapp/WeChat | +8618926420256 | |
trade manager | cn1520921554ejfd | |
Name | Dani Huang | |
Product Description
parameter | |||
system | language | Chinese/English/Russian/Korean (optional) | |
Operation interface | OSD menu | ||
password security | User password and administrator password, two-level management (default password: 111111) | ||
video | video input | A: Support 4-channel CIF/HD1/D1/960H/720P AHD/1080P AHD camera synchronous video playback | |
video output | 3-way video output (RCA, 20PIN interface, VGA HD output) | ||
video display | Support 1~4 screen display (choose your own preview method) | ||
video standard | PAL or NTSC | ||
Image Compression | H.265 Main profile, PAL: 120fps 1080P/s, NTSC: 120pfs 1080P/s | ||
sound | audio input | 4 audio inputs | |
Audio output | 1 channel audio output | ||
recording method | Simultaneous audio and video recording | ||
Image Processing and Storage | image format | CIF/HD1/D1/960H/720P/1080P optional | |
video streaming standard | ISO14496-10 | ||
video bitrate | CIF: 1536Kbps ~ 128Kbps | ||
HD1/D1: 2048Kbps ~ 400Kbps | |||
960H: 2048Kbps ~ 400Kbps | |||
720P: 4096Kbps ~ 400Kbps | |||
1080P:2048Kbps ~ 8192Kbps | |||
8 levels of image quality are optional, level 1 is the highest and level 8 is the lowest | |||
audio bitrate | 40Kbps | ||
data storage | Support two 256G SD cards | ||
alarm | Alarm input | 4-way alarm input, configurable for low-level alarm below 1V or high-level alarm above 5V | |
Alarm Output | 1 output, high level 12V | ||
Communication Interface | RS485 interface | Support 1 RS485 interface | |
RS232 interface | Support 1 RS232 interface | ||
RJ45 interface | Support network cable | ||
USB interface | 1*USB for software upgrade and video file copy | ||
Wireless communication | 3G | Built-in 3G communication module (HSUPA/HSDPA/WCDMA/EVDO/TD-SCDMA) | |
4G | Built-in 4G communication module (FDD-LTE/TDD-LTE) optional | ||
Wifi | Built-in WiFi module (2.4/5.8GHz) optional | ||
Global Positioning System | Built-in GPS module, can write geographical coordinates, speed and other data into the code stream, and can upload wirelessly | ||
sensor | Built-in gravity sensor | ||
supporting software | PC-side playback analysis | Play back the video on the PC and analyze the vehicle information in the file | |
CMS management software | Use video preview, GPS upload, alarm upload and parameter configuration via wireless network | ||
software upgrade | Support SD card/USB2.0 interface and CMS platform remote upgrade | ||
2. Support 4 channels of 1080P / 960P / 720P / D1 mode audio and video recording and playback at the same time, up to 4 channels (1080P AHD / 720P AHD / 960H) simultaneous audio and video recording;
3. Support setting mirror image; Ø Built-in reversing ruler line;
4. Using aviation joints, high stability and strong shock resistance;
5. Built-in 3G network, GPS module;
6. Using the same kind of UPS patented power-off protection technology, it can still work for 3-8 seconds when the external power supply is cut off, so as to prevent accidental damage to video files (customization is required);
7. Good scalability, with 1 RS485 interface (optional), 1 RS232 interface (232 interface can be connected with third-party equipment such as fuel sensor, temperature and humidity sensor, ADAS, DMS, OBD2, passenger counter;
8. Support 2*SD card, maximum support 256GB;
9.8V-36V wide voltage DC power supply, support 12V regulated output power supply;
10. It supports hard disk heating technology and can work at -40°C-+70°C.
power input | +8～+36V | 8V～36V, (Please confirm the power supply voltage of the car battery before use, if it exceeds 36V for a long time, it will burn out machine. ) | |
power output | 12V | 12V (+/-0.2V), maximum current: 2A | |
ACC detection | ≤5V | turn off | |
≥5V | Open | ||
Video input impedance | 75Ω | Each video input impedance: 75Ω | |
Video output voltage | 2Vp-p | 2VP-P CVBS outputs analog signal, monitor input needs 75Ω impedance to adapt. | |
input/output interface | less than 1V | low level alarm | |
Greater than 5V | High alarm | ||
Operating temperature | -40℃～60℃ | in a well-ventilated environment | |
aspect | 147*145*41.2mm | ||
optional features | ADAS: Advanced Driver Assistance System DMS: Driver Monitoring System | ||
