XVR4104HS-I 4-channel Penta-brid 1080N/720p Compact 1U 1HDD WizSense Digital Video Recorder Dahua AI 4-channel DVR

system

main processor

embedded processor

operating system

Embedded Linux

patch plus

Performance

4 channels

Artificial intelligence search

Search by target category (people, vehicles)

Video and audio

Analog camera input

4 channels, BNC

HDCVI camera input

1080p@25/30 frames, 720p@50/60 frames, 720p@25/30 frames

AHD camera input

1080p@25/30 frames/second, 720p@25/30 frames/second

TVI camera input

1080p@25/30 frames, 720p@25/30 frames

CVBS camera input

PAL/NTSC

IP camera input

4+1 channels, maximum 2MP per channel

Audio input/output

1/1, RCA

Two-way conversation

Reuse audio input/output, RCA

Record

compression

AI encoding/H.265+/H.265/H.264+/H.264

solve

1080N; 720p; 960H; D1; CIF

Recording rate

Mainstream:

4 channels: all channels 1080N/720p/960H/D1/CIF/(1 fps–25/30 fps)

Substream:

4 channels: CIF/(1 fps–15 fps)

bitrate

32 kbps–6144 kbps per channel

Recording mode

Manual; Schedule (General, Continuous); MD (Video Detection: Motion Detection, Video Loss, Tampering); Alarm; Stop

Logging interval

1 minute – 60 minutes (default: 60 minutes), pre-recording: 1 second – 30 seconds, post-recording: 10 seconds – 300 seconds

audio compression

G.711A; G.711U; Phase change materials

Audio sample rate

8 KHz, 16 bits per channel

audio bitrate

64 kbps per channel

exhibit

interface

1 HDMI; 1 VGA

solve

1920×1080, 1280×1024, 1280×720

multi-screen display

When IP extension mode is not enabled: 1/4

When IP extension mode is enabled: 1/4/6

screen display

Camera title; time; video loss; camera lock; motion detection; recording

network

interface

1 RJ-45 port (100 Mbps)

Internet function

HTTP; HTTPS; TCP/IP; IPv4/IPv6; Wireless Internet; 3G/4G; SNMP; Universal Plug and Play; Real-time Transport Protocol; UDP; Email sending; National time planning; Dynamic Host Configuration Protocol; Domain Name System; IP filtering Server; PPPoE; Dynamic domain name server; File transfer protocol; Alarm server; Peer-to-peer; IP search (supports Dahua IP cameras, DVR, NVS, etc.)

maximum. user access

128 users

cell phone

iPhone; Tablet; Android

interoperability

ONVIF 16.12, CGI compliant

Video detection alarm

trigger event

Recording; PTZ; Travel; Video Push; Email; File Transfer Protocol; Snapshot; Buzzer and Screen Tips

Video detection

Motion detection, MD area: 396 (22 × 18), video loss, tampering and diagnostics

Alarm input

not applicable

Relay output

not applicable

Playback and backup

Playback

1/4

Search mode

Time/date, alarm, MD and exact search (accurate to seconds)

Playback function

Play; Pause; Stop; Rewind; Fast play; Slow play; Next file; Previous file; Next camera; Previous camera; Full screen; Repeat; Shuffle; Backup selection; Digital zoom

backup mode

USB device/network

storage

Internal hard drive

1 SATA port, maximum capacity 6TB

SATA

not applicable

Auxiliary interface

USB

2 USB ports (USB 2.0)

RS485

1 port for PTZ control

RS232

not applicable

electric

power supply

DC 12V/1.5A

energy consumption

(hard drive not included)

<4W

put up

aspect

Compact 1U, 260.0 mm × 237.9 mm × 47.6 mm

(10.24 inches × 9.37 inches × 1.87 inches)

net weight

(hard drive not included)

0.86 kg (1.90 lbs)

gross weight

1.37 kg (3.02 lbs)

Install

Desktop installation

environmental

Operating conditions

-10°C to +45°C (+14°F to +113°F), 0%–90% (relative humidity)

Storage conditions

-20°C to +70°C (-4°F to +158°F), 0%–90% (relative humidity)

Third party support

Third party support

Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, etc.

Certification

Certification

FCC: Part 15 Subpart B

CE: CE-LVD: EN 60950-1/IEC 60950-1

CE-EMC: EN 61000-3-2; EN 61000-3-3; EN 55032; EN 50130; EN 55024
