2000kg sliding door motor automatic sliding door operator

Product Detail

brand:smooth sailingapplication:outdoor
Maximum gate weight:2000 kgName:sliding door opener
Warranty:2 yearspayment terms:L/C, Western Union, D/P, D/A, T/T, MoneyGram
Certificate:CE / CCC / ISO9001Origin:Zhejiang, China
engine:AC motorAfter-sales service:Online technical support, on-site inspection, others
model:JY9-1200design style:industrial
port:Ningbo/ShanghaiProject solution ability:overall project solution
Packaging Details:Packing: 1 set/box GW: 15.8KG CBM: 31.2*24.2*36.5CMLimit switch:Magnetic/Spring Limit Switches
remote control:2Material:High Strength Aluminum Alloy
power supply:AC110V~240Vtype:door operator, sliding door
Supply capacity:5000 sets per month
Product Description

Item No. JY3-1200



Motor power 1200W



Power AC220V 50HZ/AC120V 60HZ



Output torque 45N.m



Maximum door weight 2000KG



Motor speed 1400r/min



Gate speed 12m/min



Limit Switch Spring/Magnetic (NO/NC)



Noise≤56dB



Temperature -45°----+65°



Protection class IP44



CCC/CE certificate



feature:

1. Soft start and stop, avoiding the impact of the door when opening and closing.

2.A alloy die-casting mechanism, powder sprayed, stable.

3. Electromechanical stroke limit switch, double protection, accurate positioning.

4. Emergency release key in case of power failure.

5. Optional wire control or remote control.

6. Moving indication - the indicator light is on when the door is moving.

7. Infrared protection to ensure high security.

8. The opening and closing limit has a self-locking function.

9. Built-in maximum motor running time (MRT) adjustable, multiple safety protection.

10. The motor coil is made of copper.

11. Motor winding built-in thermal protection.

12. The gear has a protection device, and the driving device is composed of a worm gear and a worm, and it works smoothly.



Packaging and Shipping

Packaging details: 1. Normal export 1set /carton

2. Pallet available

3. According to customer requirements



Delivery details: 1.7-15 working days from 30% deposit, delivery after receiving the balance

2. Send samples by express UPS, TNT, DHL after payment

our service

1. Your inquiry about our products or prices will be replied within 12 hours.



2. Well-trained and experienced sales staff will answer all your questions in fluent English.



3. OEM/ODM is welcome, we can help you to print your logo, company information, etc. on the product and package, protect your sales area, design concept and all private information.



4. The order will send some wearing parts for free, and all main products are guaranteed for 1 year.
