Original Omron Industrial Control 15A 250VAC 250VDC switch buckle V-154-1A5 micro switch

Product Detail

Shipping method:DHL, UPS, Fedex, TNT, EMS, ARAMEX or PostGross weight of single piece:0.100kg
brand:Omronpack:The original
Protection level:The originalquality assurance:30-365 days
Certification:The originalSales unit:Single product
model:V-154-1A5,V-154-1A5 V-155-1C5 V-156-1A5 V-156-1C25Lead:No
IP rating:IP32Switch combination:1NO1NC
Minimum order quantity:5pcsmaximum. current:15A
type:switch snapmaximum. Voltage:250VAC
Packaging details:Brand new and original, factory sealed packaging. Please contact us for more details.Single piece packaging size:25X30X25cm
Is it smart:Noagent:Shenzhen Ai Ruichen Technology Co., Ltd.
Place of origin:Japan

Body orientation: straight
Pole casting configuration: SPDT
Rated current (maximum): 15(A)
Insulation resistance: 100 (Mohm)
Operating temperature range: -25C to 105C
Product length (mm): 37.8 (mm)
Product depth (mm): 10.3 (mm)
Terminal type: quick connect
Product height (mm): 28 (mm)
Maximum working temperature ℃: 105℃
Minimum operating temperature: -25℃
Installation method: screw
Contact material: silver alloy
Switch function configuration: NO/NC
Operating force: 2.35(N)
AC rated voltage (maximum): 250
DC rated voltage (maximum): 250
Mechanical life: 50000000
Protection level: IP40
Dielectric strength: 1000VAC
Electrical life: 100,000 times
Maximum moving difference: 0.6
Minimum overtravel: 0.8
Release force: 0.49
Maximum pre-travel: 1.6
