Water-filled submersible motor winding wire

Submersible motor winding wire

Submersible pumps are widely used in special fields of industry, agriculture and daily life such as farmland irrigation, mine drainage, mineral oil, geothermal heating, and water supply without towers. The submersible motor is the driving force part of the submersible pump, suitable for wet motors in clean water, hot water, acid, alkali, salt fluid, oil or mixed liquid. The cooling of submersible pump motor winding wires can be cooled by external liquid convection cooling, mechanical seals or internal clear water or oil sealing elements, so the wires used in submersible motor windings are required to use high-quality insulating materials that are completely impermeable. Under special working conditions such as different liquid erosion, high temperature, high pressure, etc., the motor is guaranteed to run without failure and has a long service life. Our wires are specifically designed to meet the requirements of this application. The wires are made of single or multiple conductors with special plastic insulation and sheath. We have the following standard wire sizes, other special purposes or requirements can be made according to customer requirements.

Submersible motor winding wire

YF film sintered cross-linked polyethylene insulation high voltage submersible motor winding wire

This product is suitable for water-filled high-pressure submersible pump motors with AC rated voltage 500/10000V and electronic equipment working under similar conditions, and simplifies the YFPE line.

1. The rated AC voltage U./U of YFPE wire is 500/10000V

2. YFPE wire is suitable for working in water for a long time, with a pH value of 6.5-8.5

3. The long-term working temperature of YFPE wire should be less than 80°C

4. The prominent features of YFPE wires are relatively thin insulation and high voltage resistance
