Modern fashion prefabricated light steel frame small resort garden studio frame hut from China supplier
- $300.00 / >=60 square meters
- 60 square meters
- Ningbo Deepblue Smart House Co., Ltd.
- Zhejiang, China
- Ms Misty Shao
Product Detail
| model: | dolomite 2 | Advantage two: | environmentally friendly |
| Supply capacity: | 9000 square meters per month | roof: | 15mm OSB |
| pillar: | Galvanized SHS with WPC coating | Advantage: | quick assembly |
| type: | a frame house | payment terms: | L/C, Western Union, T/T |
| design style: | modern | Insulation Materials: | Glass wool or EPS/XPS/PU sandwich panel |
| life: | Structure 100 years | ceiling: | 9mm Waterproof Gypsum Board |
| The main structure: | light steel | Wall cladding: | ALC board/fiber cement board, MGO board/gypsum board |
| After-sales service: | online technical support, other | application: | hotel |
| design: | Customization | Warranty: | 1 year |
| Packaging Details: | Light steel is packed in bulk, decorative plates are packed on pallets, and all other accessories are packed into 40'HQ and 20`GP sea containers. | Project solution ability: | Graphic design, 3D model design, overall project solution |
| Origin: | Zhejiang, China | brand: | dark blue |
| port: | Ningbo, China |
No. | thing | Material | Specification |
1 | Base | fixed on the foundation | Chemical bolt |
2 | structure | steel frame wall | 0.75/0.95/1.15mm steel wall |
roof truss | 0.75/0.95/1.15mm steel truss | ||
joists (chassis) | 0.75/0.95/1.15mm steel keel | ||
3 | roof system | slats | 35mm slats |
moisture barrier | Ordinary moisture barrier | ||
watt | Elective | ||
insulation | glass wool | ||
4 | ceiling system | slats | 22mm slats |
ceiling | Gypsum/MGO board etc. | ||
insulation | glass wool | ||
5 | exterior wall | ext. wall cladding | Elective |
moisture barrier | Ordinary moisture barrier | ||
insulation | glass wool | ||
6 | interior wall | liner | Elective |
insulation | glass wool | ||
7 | floor system | under the floor | CFC/ALC board, etc. |
floor | Elective | ||
insulation | glass wool | ||
8 | kitchen (if in plan) | kitchen cabinet | Elective |
mesa | Elective | ||
sink | Elective | ||
9 | bathroom (if in plan) | Toilet | Elective |
washbasin | Elective | ||
take a shower | Elective | ||
10 | doors and windows | Exterior doors | Elective |
interior door | Elective | ||
window | Elective |
light steel structure
1) Structural life: 100 years.
2) Earthquake resistance: mixed grade 8 or above.
3) Wind resistance: maximum 60m/s.
4) Fire resistance: All materials are fire resistant.
5) Snow resistance: max 2.9KN/m² as required
6) Heat insulation: 100mm thickness can match a brick wall with 1m thickness.
7) High sound insulation: exterior wall 60db, interior wall 40db
8) Insect-proof: not harmed by insects such as termites
9) Ventilation: combination of natural ventilation or air supply to keep the indoor air fresh and clean
10) Packing and shipping: 140SQM/ 40'HQ container for structure only, 90SQM/ 40'HQ container for structure and decoration materials.
11) Installation: On average, one worker installs one SQM a day.
12) Installation guidance: send engineers on-site guidance.
Project Overview
number | design specification |
1 | AISI S100 North American Code for the Design of Cold-Formed Steel Structural Members is published in the United States by the American Iron and Steel Institute (AISI). |
2 | AS/NZS 4600 Australia/New Zealand Standard-Cold-Formed steel structure is jointly published by Standards Australia and Standards New Zealand. |
3 | BS 5950-5 Use of steel structures in construction - Part 5. Code of Practice for the Design of Cold Formed Thin Gauge Sections published by BSI UK. |
4 | ENV1993-1-3 means Euro code3: Design of steel structures, Part 1.3: General rules, supplementary rules for cold-formed thin gauge members. |
