white shaker kitchen cabinets factory wood cabinet designs

Product Detail

style:modernPlace:Fuzhou, China
brand:OEM productionWood Style:solid wood
type:kitchen cabinetSelection of color:Custom accepted
hardware:DTC soft offPackage preview:
Mail packing:noMaterial:wood, wood
place of origin; place of origin:Fujian ChinaDoor Style:Custom accepted
Certification:ISO9000Wood Type:birch
Supply capacity:30000 packs per monthmodel:shaker
appearance:modernpayment terms:L/C, D/P, D/P, T/T
port:Fuzhou/Xiamen/KronePackaging Details:Flat pack with necessary accessories



Product Description



Face frame kitchen cabinet information:

Ccomponents

feature

Door

Solid Russian birch, raised panel or shaker styles depending on your needs. Mortise and tenon joints.

Surface boxsecond

3/4" thick solid wood face frame with 1-1/2" wide sills and rails unless otherwise stated. The frame has blind tenon and tenon joints.

top, bottom and sides

1/2" thick 7-ply plywood sides/top/bottom with birch veneer pre-painted with clear UV coat interior and matching UV coat exterior. Provides matching internal options.

cabinet backrest

1/4" thick plywood and 3" x 1/2" frame, interior prepainted with UV coat. 1/2" thick back panels are available for advantage cabinets.

shelf

5/8” thick plywood, 1/2 depth, pre-painted with UV coating. Advantage cabinets are available in full depth.

drawer box

5/8" thick solid Russian birch with dovetail joints and 1/4" thick plywood bottom.

kick toes

1/2" thick plywood to cover cabinet sides.

hinge

1. DTC 4 way hidden hinge.

2. DTC soft close 6 way hidden hinge.

slide

1. 3/4 extension white base slides without soft close

2. DTC is fully extended with soft-closed slide installed.



Surface frame kitchen cabinet structure:

Frameless Kitchen Cabinets Information

Ccomponents

feature

Door

Solid Russian birch, raised panel or shaker styles depending on your needs. Mortise and tenon joints.

top, bottom and sides

3/4" thick plywood sides/top/bottom with birch veneer, pre-painted with clear UV coating on the inside and matching UV coating on the outside. Provides matching internal options.

cabinet backrest

1/4" thick plywood with pre-painted UV coating on the inside. 1/2" thick back panels are available for advantage cabinets.

shelf

3/4” thick plywood, 3/4 deep, pre-painted with UV coating. Advantage cabinets offer full depth.

drawer box

5/8" thick solid Russian birch with dovetail joints and 1/4" thick plywood bottom.

hinge

1. DTC 4 way hidden hinge.

2. DTC soft close 6 way hidden hinge.

slide

1. DTC full extension side mount slide, no soft close

2. DTC is fully extended with soft-closed slide installed.



Frameless kitchen cabinet structure:

detailed picture:



Optional door:



Completion options:





our service

  Provide OEM/ODM service



  Professional salesman service to solve your doubts



  Prompt reply within 24 hours



  Provide free samples



 Excellent quality control system
