Wholesale braided shielded 20 cores 21 cores 1.5mm zr kvvrp flexible control cable
- $0.10 / >=100 meters
- 100 meters
- Shanghai Dongdahui International Trade Co., Ltd.
- Jiangsu, China
- Ms Jiangnan Cable
Product Detail
| Conductor material: | copper | jacket: | pvc |
| insulation: | pvc | standard: | JB/T 9330-2020 and enterprise standards |
| Conductor area (mm²): | 0.5mm²-10mm² | Sheath material: | pvc |
| filter: | braided shield | application: | meter |
| payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram | model: | kvvrp |
| port: | Shanghai | product name: | PVC soft control cable |
| place of origin; place of origin: | Jiangsu, China | Supply capacity: | 1,000,000 meters per month |
| Insulation Materials: | pvc | Voltage: | 450/740V |
| nuclear: | 2-61 cores | Conductor Type: | Class1, Class2, Class5 |
| brand: | colorful |
Product Description
Wuxi Jiangnan Cable Co., Ltd.
With over 37 years of knowledge in the cable industry, we supply reliable cables worldwide. The company mainly produces 500kV and below power cables, cables for electrical equipment, and 1100kV and below bare wires in three categories, more than 100 varieties and more than 40,000 specifications. The company can also customize special wires and cables for users with various special performance requirements. The company's flexible mineral insulated fireproof cables, photovoltaic cables, electric vehicle charging cables, locomotive cables, UHV matching heat-resistant expansion core and other special cables are well received by the market and users
detailed drawing
Product parameters
product name | Copper core PVC insulated braided shielding sheathed PVC flexible control cable |
Model | KVVRP |
conductor | copper |
insulation | pvc |
sheath | pvc |
filter | braided shield |
Rated voltage | 450/740V |
kernel | 2-61 |
Conductor area(mm²) | 0.5mm²-10mm² |
standard | JB/T 9330-2020 and enterprise standards |
conductor type | Level 1,2,5 |
standard | TICW 6-2009, JB/T 13486-2018 and enterprise standards |
Rated voltage | Up to and including AC 300/500V or DC 1000V |
Conductor area(mm²) | 0.5mm²-2.5mm² |
Cable production range | ||||||||||||||||||
Types of | Conductor nominal cross-sectional area mm2 | Executive standard | ||||||||||||||||
0.5 | 0.75 | 1 | 1.5 | 2.5 | 4 | 6 | 10 | |||||||||||
Number of cores | ||||||||||||||||||
KVV, KVVP | / | 2~61 2~14 2-10 | 2~14 | 2~10 | GB/T 9330.2 | |||||||||||||
KVVP2, KVVP3 | / | 4~61 | 4~14 | 4~10 | ||||||||||||||
KVV22 | / | 7~61 | 4~61 | 4~14 | 4~10 | |||||||||||||
KVVP2-22 | / | 7~61 | 4~61 | 4~14 | 4~10 | |||||||||||||
KVV32 | / | 19~61 | 7~61 | 4~14 | 4~10 | |||||||||||||
KVVR | 2~61 | / | / | / | / | |||||||||||||
KVVRP | 2~61 | 2~48 | / | / | ||||||||||||||
Note: 1) Preferred number of cores: 2, 3, 4, 5, 7, 8, 10, 12, 14, 16, 19, 24, 27, 30, 37, 44, 48, 52, 61 2) Flame retardant, flame retardant, low halogen low smoke, halogen free low smoke and other special models Acid and alkali resistant cables for these cables are available upon request. | ||||||||||||||||||
